Dytran, Inc. of the United States released the 3056F model in 2024.
The 3056F models were developed to replace the 3056D model, and a feature to desensitize electromagnetic waves has been added to the existing general and high-temperature 3056D models.
Click the image above to go to the blog's main page
The Dytran Series 3056F models are wide-bandwidth single-axis vibration accelerometers used for modal analysis, environmental testing, semiconductor lines, automotive vibration, marine, aviation and defense testing, vibration control, and general vibration monitoring. In other words, they feature a wide measurement frequency range, environmental performance capable of measuring up to +163°C, and base isolation, making them suitable for a wide range of applications.
Please check the changes from the 3056D series to the 3056F series models in the table below before placing an order.
| Measurement Range |
Sensitivity | 3055F (Operating temperature: -55 ~ +163) |
3055D (Operating temperature: -55 ~ +121/+107) |
3055D (Operating temperature: -55 ~ +163) |
| 1,000 g | 5 mV/g | 3056F2 | 3056D8 | |
| 500 g | 10 mV/g | 3056F3 | 3056D1 | 3056D9 |
| 250 g | 20 mV/g | 3056F4 | 3056D4 | 3056D10 |
| 100 g | 50 mV/g | 3056F5 | 3056D5 | 3056D11 |
| 50 g | 100 mV/g | 3056F6 | 3056D2 | 3056D12 |
| 25 g | 200 mV/g | 3056F7 | 3055D6 | 3056D13 |
| 10 g | 500 mV/g | 3056F8 | 3056D3 | 3056D14 |
Clicking on the 3056F models will take you to a blog where you can download the data sheets.
